TE8590C
TEDDERS
MSRP AS LOW AS
$0.00
Special Offers
Stand Alone Financing Installment Program
Implement Stand Alone Financing
Customer instant rebate for Farmer Veteran Coalition members.
Farmer Veteran Coalition Rebate
Up to 0% A.P.R. for 48 Months on your new Kubota TE Series!
TEDDER SERIES
Easy Transport
Kubota's TE8590C is easily converted from working to transport position. Wheels are fixed during transport for smooth and stable running. This can all be done from the tractor seat, only requiring on 1 set of hydraulic outlets. Model is approved for 25 mph.
Super-C Tine
The symmetric Kubota Super-C tines efficiently pick up the crop from two different areas. As it spreads the crop, the crop is inverted so the lower crop is placed on the top, giving a more even dry down. The crop is then spread evenly across the width of the machine for consistent drying. These tines are made of 0.39" shot-peened spring steel. Our spring coil diameter has a 20% larger diameter than conventional designs. This increases each tine service life, even when tedding heavy, high moisture crops.
Rotor Gearbox
These Kubota tedder models have a maintenance-free, oil-immersed gearbox, which means less time required for servicing and more time in the field. The gearboxes are integrated into the frame, making them extremely durable. Because they are not part of the frame structure, but are mounted within the actual frame, the gearbox is relieved of frame stresses.
Large Working Widths
Even with large working widths, due to their trailed design these tedders are still ideal for lower horsepower tractors. This minimizes compaction and operating costs – certainly a great advantage in times of escalating fuel and labor costs.
- TE6583T – 27'3"
- TE8590C – 29'6"
- TE8511T – 36’1”
- TE10511C – 36'9"
Specs & Compare
Compare models.
TE8590C
HP
MSRP AS LOW AS
$0.00
Specifications
Adjustment Of Spreading Angle
Cab Contr. Border Clearing System, Hydr.
Cab Contr. Border Clearing System, Mech.
Capacity Theor. Acres/h
Farm Line
Front Wheel (16x6.50-8)
Linkage Drawbar
Number Of Rotors
Number Of Tine Arms/ Rotors
Pro Line
Reduction Gearbox For Night Windrows
Storage Height Ft. (m)
Tandem Axles
Three- Point, Tracking
Tine Adjustment System
Tires On Central Unit
Transport Length Ft. (m)
Transport Width Ft. (m)
Two- Point, Linkage Arms
Vibration Damper/ Integral Lock
Warning Panels
Warning Panels With Integr. Lighting
Weight Lbs. (kg)
Wheels (4)
Width, Working Position Ft.
Working Width Ft. (m)
Adjustment Of Spreading Angle
Standard
Cab Contr. Border Clearing System, Hydr.
Standard
Cab Contr. Border Clearing System, Mech.
N/A
Capacity Theor. Acres/h
N/A
Farm Line
Standard
Front Wheel (16x6.50-8)
Standard
Linkage Drawbar
N/A
Number Of Rotors
8
Number Of Tine Arms/ Rotors
7
Pro Line
N/A
Reduction Gearbox For Night Windrows
Optional
Storage Height Ft. (m)
12 ft 3 in
Tandem Axles
Optional
Three- Point, Tracking
N/A
Tine Adjustment System
N/A
Tires On Central Unit
N/A
Transport Length Ft. (m)
13 ft 10 in
Transport Width Ft. (m)
9 ft 7 in
Two- Point, Linkage Arms
Cat ll
Vibration Damper/ Integral Lock
N/A
Warning Panels
Standard
Warning Panels With Integr. Lighting
Standard
Weight Lbs. (kg)
3747 (1700)
Wheels (4)
N/A
Width, Working Position Ft.
31ft 0 in
Working Width Ft. (m)
29 ft 6 in
